Thru-Beam Sensors up to +600 °C

Thru-Beam Sensors with Easy Color Adjust (LX series)

High-range light barriers from the LX series (with Easy Colour Adjust) are the latest generation of Proxitron light barriers. They allow a wide range of functions and an extremely long range when detecting hot and cold objects, even in difficult ambient conditions.

Product selection

Find out more about our thru-beam light barriers from the LX series with Easy Colour Adjust.

5060ALXAA 600.3 S4 Thru-Beam Sensor , Transmitter , -25°C up to 70°C
Range: 2500 mm,
12 - 55V DC , Air Connection , Cooling Jacket, Housing Material: Edelstahl,Length: 196mm , Ø57mm , Plug , with Test function ,

Data sheet »
5061ALXSA 600.3A GV S8 Thru-Beam Sensor , Receiver , -25°C up to 70°C
Range: 2500 mm,
12 - 55 VV DC , Air Connection , Cooling Jacket, Housing Material: Edelstahl,Length: 196mm , Ø57mm , Plug ,

Data sheet »
5068BLLXSA 600.3A GV S8 Laser Einweg-Lichtschranke , Receiver , -25°C up to 70°C
Range: 2500m,
12 - 55V DC, Housing Material: Edelstahl,Length: 171mm , Ø57mm , Plug ,

Data sheet »
5060BLXAB 600.3 S4 Thru-Beam Sensor , Transmitter , -25°C up to 200°C
Range: 2500 mm,
12 - 55V DC , Air Connection , Cooling Jacket, Housing Material: Edelstahl,Length: 196mm , Ø76mm , Plug , with Test function ,

Data sheet »
5062ALXUA 600.3A GV S8 Thru-Beam Sensor , , -25°C up to 70°C
Range: 65m,
12 - 55V DC, Housing Material: Edelstahl,Length: 196mm , Ø57mm , Plug ,

Data sheet »
5062ALXUA 600.3A GV S8 Reflex-Lichtschranke , , -25°C up to 70°C
Range: 65m,
12 - 55V DC, Housing Material: Edelstahl,Length: 196mm , Ø57mm , Plug ,

Data sheet »
5062ALXUA 600.3A GV S8 Diffuse sensor , , -25°C up to 70°C
Range: 6m,
12 - 55V DC, Housing Material: Edelstahl,Length: 196mm , Ø57mm , Plug ,

Data sheet »
5062BLXUB 600.3A GV S8 Reflex-Lichtschranke , , -25°C up to 200°C
Range: 65m,
12 - 55V DC , Air Connection , Cooling Jacket, Housing Material: Edelstahl,Length: 196mm , Ø76mm , Plug ,

Data sheet »
5062BLXUB 600.3A GV S8 Diffuse sensor , , -25°C up to 200°C
Range: 6m,
12 - 55V DC , Air Connection , Cooling Jacket, Housing Material: Edelstahl,Length: 196mm , Ø76mm , Plug ,

Data sheet »

Electronics and fibre optic cables

5065ALXAD 600.3 Thru-Beam Sensor , Transmitter , -25°C up to 70°C
Range: 400 m mit LXSA/LXSB 600, 250 m mit LXSD 600m,
12 - 55V DC , Air Connection , Cooling Jacket, Housing Material: Aluminium,Length: 125mm , Plug ,

Data sheet »
5066ALXSD 600.3A GV Thru-Beam Sensor , Receiver , -25°C up to 70°C
Range: 750 m mit LXAA/LXAB 600, 250 m mit LXAD 600m,
V , Air Connection , Cooling Jacket, Housing Material: Edelstahl,Length: 125mm , Plug ,

Data sheet »
5063ALXUD 600.3A GV Thru-Beam Sensor , Transmitter , -25°C up to 70°C
Range: 250m,
12 -55V DC , Air Connection , Cooling Jacket, Housing Material: Edelstahl,Length: 125mm , Plug ,

Data sheet »
5063ALXUD 600.3A GV Reflex-Lichtschranke , , -25°C up to 70°C
Range: 42,5m,
12 -55V DC , Air Connection , Cooling Jacket, Housing Material: Edelstahl,Length: 125mm , Plug ,

Data sheet »
5063ALXUD 600.3A GV Diffuse sensor , , -25°C up to 70°C
Range: 1,8m,
12 -55V DC , Air Connection , Cooling Jacket, Housing Material: Edelstahl,Length: 125mm , Plug ,

Data sheet »
6436FLLK2 Fiber Optic Cable , -20°C up to 290°C

Data sheet »
6436ILLK4 Fiber Optic Cable , -20°C up to 290°C

Data sheet »
6436JLLK5 Fiber Optic Cable , -20°C up to 290°C

Data sheet »
6436MLLK6 Fiber Optic Cable , -20°C up to 290°C

Data sheet »
6436KLLK8 Fiber Optic Cable , -20°C up to 290°C

Data sheet »
6436LLLK 10 Fiber Optic Cable , -20°C up to 290°C

Data sheet »
6436QLLK15 Fiber Optic Cable , -20°C up to 290°C

Data sheet »
6436PLLK20 Fiber Optic Cable , -20°C up to 290°C

Data sheet »

Weiteres Zubehör für unsere Einweg-Lichtschranken >>

Are you looking for a reliable thru-beam light barrier for use in your application?

Potete contattarci via mail all’indirizzo sales•@•proxitron.de, o mediante il nostro contact form, o telefonicamente al n. +39-02-96328773.
Il nostro team sarà lieto di assisterVi fornendo tutte le informazioni necessarie!

Altre informazioni e aiuti nella selezione

selettore

brochure

Questionari applicativi
